Precessing width： 600mm 800mm 1000mm 1300mm 1600mm

Processing thickness ：0.5-100mm

Feeding table adsorption method: strong permanent magnetic adsorption (minimum sizeof the workpiece : 20*20), vacuum adsorption (minimum size of the workpiece ≥ 50*50).semi-magnetic and sems-vacuumm adsorpton

Automatic thickness setting device: synchronous lifting of four-column connecting rods.lifting servo motor lifting accuracy ± 0.0lmm

Processing speed: conveying speed 0,3m-9mVmin (frequency conversion adjustable)Thousand wire wheel speed 5m's-20my's (frequency conversion adjustable)

The whole machine plc controls the touch screen to adjust paramatersConfigure wet industrial dust collactor or pulse flame retardant dust collector to processdust to achieve safe and environmentally friendly production

This deburring machine support laser cutting machine, CNC stamping, various CNC processing or other machining deburring front production line. It can work by through straight line processing, sanding belt and multiple groups of sanding line wheel rotation, revolution, alternate, can be a real uniform removal of parts surface, contour edge and hole edge burr and uniform chamferin

The universal roller brush structure, with the abrasive roller brush rotating at high speed, rubs and taps the edges of the workpiece surface, making the contours around the surface and within the holes smooth and rounded, resulting in a chamfered effect.
